General Specification

Frequency Bands

380-430MHz / 405-475MHz / 806-870MHz

Dimensions (HxWxD)

127.5 x 55 x 43.mm

Weight

408g (with battery and antenna)

Battery

2400mAh Li-Ion battert

Battery Life (TMO 5-5-90 duty cycle)

> 24 Hours (2400mAh)

Operating Voltage

7.4V

User Interface

LCD Colour Display

1.8inch, 160*128 pixels, 65536 colours

Talk group-TMO.

6000

Talk group-DMO.

4000

Phone Book

2000

lnbox

400

Outbox

50

Drafts

50

Folder-TMO

200

Folder-DMO

50

State Message

200

RF Specification

RF Channel Bandwidth

25KHz

RF Power Output

1W

RF Power Level Accuracy

±2dB

RF Power Control

5dB per step, 4 levels and 3 steps in total

Receiver Class

ETSI EN 392-2/396-2 Class A & Class B

RX Static Sensitivity

≤-116dBm(typical-118dBm) 806-870MHz: ≤-115dBm(typical-116dBm)

RX Dynamic Sensitivity

≤-107dBm(typical-109dBm) 806-870MHz: ≤-106dBm(typical-107dBm)

Audio Power Output

2W

GPS Specifications (For the Model with GPS)

Sensitivity

< -146dBm Acquisition Sensitivity < -165dBm Tracking Sensitivity

Horizontal Position Accuracy

≤2.5m (50% probable) @-130dBm

Cold Start (Time to First Fix)

35s

Hot Start (Time to First Fix)

1s

Note

Conditions: Open Sky environment, 130dBm signal strength, 24H static

Environmental

Operating Temperature

-30°C - +60°C (non-hazardous environment) -30°C - +55°C (hazardous environment)

Storage Temperature

-40°C - +85°C

Humidity

ETS 300 019 -1-7 Class 7.3E; MIL-STD 810G

Water and Dust Protection

IP65/66/67/68 Per IEC60529

Drop, Shock & Vibration

ETS 300 019 -1-7 Class 5M3; MIL-STD 810 G GJB150A-2009
